Divider Box Generator

An organizer box with a lid where every row gets its own number of compartments, and the dividers lock into the walls and into each other.

Settings

Units

Inside size

mm
mm
mm

Compartments

Rows
Rows run from the back of the box to the front.
Row 1 compartments
Each compartment is 220mm wide and 51mm deep.
Row 2 compartments
Each compartment is 71mm wide and 51mm deep.
Row 3 compartments
Each compartment is 71mm wide and 51mm deep.
Lower dividers make small items easier to pick out.
mm
Lock dividers into the walls
Tabs pass through slots in the walls. Turn off for a removable insert that lifts out and keeps the outside walls clean. Dividers with nothing to lean on still lock into the walls.
Finger notches
A round notch in the top of each short divider.

Lid

Slip-over lid
A lift-off lid that slips down over the walls.
mm
Gap on each side between the box walls and the lid.
mm

Construction

mm
mm

Vector Export

3D Print Design

The STL and 3MF are ready to print: the box is one solid piece with locked dividers built in, or with lift-out dividers as one separate insert. The lid prints upside down beside it.

3MF preserves richer print metadata when your slicer supports it.

Inspirational Palette
673mm × 515mm
(26.5in × 20.3in)

Examples

Cut from white acrylic. One long compartment at the back and two rows of three in front of it, with finger notches in the short dividers. The dividers lock into the walls and each other.

White acrylic organizer box cut on a laser, with three rows of compartments beside its slip-over lid

Materials used:

Set the material thickness to match your sheet before cutting, since every tab and slot is sized from it.

How To Use

Frequently Asked Questions

Yes. Set the number of rows, then pick the compartments for each row. The long dividers run across the box between rows, and the short dividers sit inside each row.

With locking on, every divider has tabs that pass through slots in the walls or in the crossing divider, so the grid holds itself. Turn locking off to make the grid a removable insert that lifts out in one piece.

No. The dividers are never taller than the inside height, and the lid sits on top of the walls.

Visit the MyLaserTools Learning Center for a step-by-step Divider Box Generator guide, plus material tips and file-format help for laser cutting, CNC, and 3D printing. The guides walk you through every setting and how to prepare your files for your machine.

Open the Divider Box Generator guide

About

This free divider box generator lays out a finger-jointed organizer box with compartments you plan row by row: a single long tray at the back and a grid of small cells in front, or any mix you need. The dividers lock into the walls and into each other with tabs that never collide, so the grid stays square without glue in every joint. Add finger notches and a slip-over lid and use it for tea, jewellery, craft supplies, screws or game pieces.
