Tray Layout Generator
A divided tray whose egg-crate dividers cross-lock and drop straight in, carving a drawer into a neat grid of compartments.
Settings
Dimensions
Construction
Compartments
Vector Export
3D Print Design
The STL prints in place as one welded piece. The 3MF is a zip of separate panels for flat printing or laser cutting.
3MF preserves richer print metadata when your slicer supports it.
Generate a design to see the 2D preview
Generate a design to see the export preview
Examples
Laser cut in TruFlat® Cherry plywood. The egg-crate dividers slot together and drop into the tray to make a tidy grid of compartments.
Material used:
Set the thickness slider to match your sheet before cutting, since every slot and finger joint is derived from it.
How To Use
Frequently Asked Questions
Yes. Set the grid, size and depth you want, then download the SVG or the print-ready parts with no watermark and no export limits.
The dividers use cross-lap notches so the horizontal and vertical strips slot into each other and drop into the tray as a rigid grid, no glue required. Choose how many columns and rows you want to size each compartment.
Set the thickness slider to your actual sheet thickness before exporting, because every cross-lap notch is derived from it. Measure the sheet rather than trusting the label so the dividers lock together with a clean press fit.
Yes. A commercial license is included, so you can sell trays made with the tool on Etsy, at craft fairs, or anywhere else. Attribution is appreciated but not required.
Visit the MyLaserTools Learning Center for a step-by-step Tray Layout Generator guide, plus material tips and file-format help for laser cutting, CNC, and 3D printing. The guides walk you through every setting and how to prepare your files for your machine.
Open the Tray Layout Generator guideAbout
This free tray layout generator lays out a finger-jointed tray divided into a grid of compartments by interlocking egg-crate dividers. The dividers cross-lap together and drop into the tray, so there is no glue needed inside. Ideal for drawer organizers, desk trays, sewing kits, and parts storage.
